We often received the question whether LUMIN also has inputs, no unfortunately, was then the answer. Good news! The P1 mini has them. This dac streamer, features a volume control and has multiple digital inputs. A powerful dynamic dac. Bright, as LUMIN is by definition.
This device combines a streamer, DAC and preamplifier in one compact enclosure. It features five inputs, including USB, HDMI, SPDIF and analog, and supports DSD512 and PCM384. The dual ES9028PRO DAC chips and Femto Clock System with precision FPGA distribution ensure accurate signal processing. With the internal linear power supply and Leedh Processing for lossless volume control, the device offers reliable and efficient operation. Dual network ports, including optical fiber network support, enable flexible network connectivity. In addition, it is compatible with streaming services such as TIDAL, Qobuz and Spotify, and supports AirPlay and Roon Ready functionality. The included infrared remote offers easy control of functions such as input selection and volume control.
Network playback: Up to DSD512, up to 384 kHz, 16–32-bit, Stereo, MQA Full Decoding Upsampling rates & bit depths: DSD256 upsampling option for all files, PCM 384 kHz upsampling option for all files Digital inputs: USB: USB Audio Class 2 compatible, Windows 10 (Release 1703 or later) / Mac OS X or later, DoP 128 support, PCM 44.1–384 kHz, 16 / 32-bit, Stereo; OPTICAL/SPDIF: PCM 44.1 kHz–192 kHz, 16–24-bit, DSD64 (DoP64, DSD over PCM); HDMI: PCM 2.0 audio support, 4K video pass-through Digital outputs: USB: Native DSD512 support, PCM 44.1–384 kHz, 16–32-bit, Stereo; BNC SPDIF: PCM 44.1 kHz–192 kHz, 16–24-bit, DSD64 (DoP64, DSD over PCM); HDMI: HDMI pass-through and ARC support, PCM 2.0 audio support, 4K video pass-through, ARC (Audio Return Channel) support; Analog input: RCA Stereo x1; Analog outputs: Dual ESS SABRE32 ES9028Pro DAC chips, Fully balanced layout with high-quality components, Femto Clock System with precision FPGA distribution Optical network: Industry-standard Gigabit SFP, 1000Base-T Gigabit Ethernet; an adapter may be required for your specific switch or cables; use simultaneously with RJ45 (e.g., connect one to the router and one to the LUMIN L1 or NAS) Power supply: Internal toroidal linear, low-noise linear regulator Dimensions and weight: 400 mm (W), 314 mm (D), 77 mm (H), 7 kg
The LUMIN A1 was designed by the Hong Kong-based LUMIN team as the brand's first product. The design combines audiophile performance with ease of use, developed by a team with experience in high-end audio and software. The enclosure is milled entirely from solid aluminum for optimal shielding and vibration damping. Internally, they use high-quality ESS SABRE DACs and a linear power supply.
In 2012, LUMIN introduced the world's first network player capable of playing DSD files. After two years of development and hundreds of hours of critical listening, this product was launched with a single forum post. Since then, LUMIN has expanded its lineup to nine models, ranging in price points. All products share a focus on natural music playback, continuous software development and a seamless streaming experience. In recent years, LUMIN has added support for services such as Roon, MQA and Spotify. In addition, the company has introduced features such as Leedh Processing, a digital volume control technology. LUMIN develops hardware, firmware and software internally, allowing for rapid implementation of new features.
